wholesale 16 series Inch size double row deep groove ball bearing 1616 2RS for sprag clutch

FOB Reference Price:Get Latest Price
$1.00 - $5.00 / Piece | 1.0 Piece/Pieces (Min. Order)
Brand Name:
OEM
Outside Diameter:
1 - 100000 mm
Shipping:
Support Express · Sea freight · Land freight · Air freight
Report Suspicious Activity
Overview
Quick Details
Type:
BALL
Structure:
Deep Groove
Applicable Industries:
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
Bore Size:
0.1 - 10000 mm
Model Number:
1616 2RS
Precision Rating:
ABEC1 ABEC3 ABEC3 ABEC5
Seals Type:
-RS -2RS -Z -ZZ OPEN
Number of Row:
DOUBLE ROW
Place of Origin:
Shanghai, China
color:
black
size:
has all type
name:
hybrid ball bearing
other name:
inch stainless steel ball bearing
orgin:
made in shanghai
brand:
OEM
model:
has A variety of different models
use:
Used in industry and medicine
structure:
ball bearing
characteristics:
High temperature resistant strong acid and alkali
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month 1000 piece Inch size ball bearing 1616
Packaging & Delivery
Packaging Details
Inch size ball bearing 1616 use Wooden box, plastic, carton or according to customer requirements
Port
shanghai
Picture Example:
package-img

Related Products


Product Description

wholesale 16 series Inch size double row deep groove ball bearing 1616 2RS for sprag clutch

Bearing Data

P/N S6002-2RS or S6002 RS
Brand OEM
Material AISI 440 Stainless Steel
Dimension 15x32x9 mm
Precision ABEC-1,3,5 Available
Vibration V1, V2, V3 Available
Play or Clearance C0, C1, C2, C3 Available
Noise Z1, Z2, Z3 Available
Closure Type Rubber Sealed
Speed RPM 27,000
Load Cr N 4,340
Load Cor N 1,910



The deep groove ball bearing are the most widely used type of bearings, are able to operate at high or even very high speeds,



The raceway grooves on both the inner and outer rings have circular arcs of slightly larger radius than that of the balls.



In addition to radial loads, axial loads can be imposed in either direction. Because of their low torque,



they are highly suitable for applications where high speeds and low power loss are required. in relation to any of the







Product list



6000 Series



N0.

Bore

O.D Width Chamfer Load Rating Maximuum Seed Weight

mm

mm mm mm

Dynamic

Cr

Static

Cor

Grease

r/min

Oil

r/min

Kg/pcs
604 4 12 4 0.2 0.97 0.36 36000 44000 0.0021
605 5 14 5 0.2 1.33 0.505 32000 40000 0.0035
606 6 17 6 0.3 2.19 0.865 30000 38000 0.006
607 7 19 6 0.3 2.24 0.91 28000 36000 0.008
608 8 22 7 0.3 3.35 1.4 26000 34000 0.012
609 9 24 7 0.3 3.4 1.45 24000 32000 0.014
6000 10 26 8 0.3 4.55 1.96 22000 30000 0.019
6001 12 28 8 0.3 5.1 2.39 19000 26000 0.021
6002 15 32 9 0.3 5.6 2.83 18000 24000 0.03
6003 17 35 10 0.3 6.8 3.35 17000 22000 0.039
6004 20 42 12 0.6 9.4 5.05 15000 19000 0.069
6005 25 47 12 0.6 10.1 5.85 14000 18000 0.08
6006 30 55 13 0.6 13.2 8.3 12000 15000 0.116
6007 35 62 14 1.0 16 10.3 10000 14000 0.115
6008 40 68 15 1.0 16.8 11.5 8000 11000 0.19



6200 Series



N0.

Bore

O.D Width Chamfer Load Rating Maximuum Seed Weight

mm

mm mm mm

Dynamic

Cr

Static

Cor

Grease

r/min

Oil

r/min

Kg/pcs
624 13  0.2  1.15  0.4  36000  45000  0.0032
625 16  0.3  1.76 0.680 32000  40000  0.0050
626  19  0.3 2.34  0.885  28000  36000  0.0080
627  22  0.3 3.35  1.400  26000  34000  0.0130
628  24  0.3 4.00  1.590  24000  32000  0.0170
629  26 0.3 4.55  1.960  22000  30000  0.0190
6200  10  30 0.6 5.10  2.390  19000  26000  0.0300
6201  12  32 10  0.6 6.10  2.750  18000  24000  0.0360
6202  15  35 11  0.6 7.75  3.600  17000  22000  0.0460
6203  17  40  12  0.6 9.60  4.600  16000  20000  0.0650
6204  20  47 14  1.0 12.80  6.650  14000  18000  0.1070
6205  25  52  15  1.0 14.00  7.850  12000  16000  0.1250
6206 30  62  16  1.0 19.50  11.300  10000  13000  0.2010





6300 Series



N0.



Bore

O.D Width Chamfer Load Rating Maximuum Seed Weight

mm

mm mm mm

Dynamic

Cr

Static

Cor

Grease

r/min

Oil

r/min

Kg/pcs
6300

10

35 11 0.6

8.2

3.5

18000

24000

0.053
6301 12 37 12 1.0 9.7 4.2 17000 22000 0.06
6302 15 42 13 1.0 11.4 5.45 16000 20000 0.082
6303 17  47  14  1.0  13.5  6.55  15000  19000  0.115
6304  20  52 15  1.1  15.9  7.9  14000  17000  0.144



6800 Series



N0.





Bore

O.D Width Chamfer Load Rating Maximuum Seed Weight

mm

mm mm mm

Dynamic

Cr

Static

Cor

Grease

r/min

Oil

r/min

Kg/pcs
685

5

11 3 0.15

0.715

0.282

35000

45000

0.0011
686 6 13 3.5 0.15 1.08 0.44 33000 42000 0.0019
687 7 14 3.5 0.15 1.17 0.505 31000 40000 0.0021
688 8 16 4 0.2 1.61 0.715 29000 38000 0.0031
689 9 17 4 0.2 1.72 0.82 28000 36000 0.0032
6800 10 19 5 0.3 1.83 0.925 26000 34000 0.005
6801 12 21 5 0.3 1.92 1.04 22000 30000 0.006
6802 15 24 5 0.3 2.08 1.26 20000 28000 0.007
6803 17 26 5 0.3 2.23 1.46 19000 26000 0.008
6804 20 32 7 0.3 4 2.47 17000 22000 0.019
6805 25 37 7 0.3 4.3 2.95 15000 19000 0.022
6806 30 42 7 0.3 4.7 3.65 13000 17000 0.026
6807 35 47 7 0.3 4.9 4.05  11000  15000  0.029



6900 Series



N0.







Bore

O.D Width Chamfer Load Rating Maximuum Seed Weight

mm

mm mm mm

Dynamic

Cr

Static

Cor

Grease

r/min

Oil

r/min

Kg/pcs
693

3

8 3 0.15

0.56

0.18

44000

52000

0.0006
694 4 11 4 0.15 0.715 0.276 38000 47000 0.0018
695 5 13 4 0.2 1.08 0.43 34000 43000 0.0024
696 6 15 5 0.2 1.35 0.53 32000 40000 0.0038
697 7 17 5 0.3 1.61 0.715 30000 38000 0.0052
698 8 19 6 0.3 1.99 0.865 28000 36000 0.0073
690 9 20 6 0.3 2.48 1.09 27000 34000 0.0082
6900 10 22 6 0.3 2.7 1.27 25000 32000 0.009
6901 12 24 6 0.3 2.89 1.46 20000 28000 0.011
6902 15 28 7 0.3 3.65 2 19000 26000 0.016
6903 17 30 7 0.3 4.65 2.58 18000 24000 0.018
6904 20 37 9 0.3 6.4 3.7 17000 22000 0.036
6905 25 42 9 0.3 7.05 4.55 14000 18000 0.042
6906 30 47 9 0.3 7.25 5 12000 16000 0.048
6907 35 55 10 0.3 9.55 6.85 10000 14000 0.074
